Camera

Image Sensor 1/2.8″ CMOS
Max. Resolution 1920 (H) × 1080 (V)
ROM 128 MB
RAM 128 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.002 Lux@F1.6 (Color, 30 IRE)
0.0002 Lux@F1.6 (B/W, 30 IRE)
0 Lux (Illuminator on)
S/N Ratio > 56 dB
Illumination Distance 40 m (131.23 ft) (IR)
Illuminator On/Off Control Auto; manual
Illuminator Number 2 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355°

Lens

Lens Type Motorized vari-focal
Focal Length 2.7mm–13.5mm
Lens Mount φ14
Max. Aperture F1.5
Field of View
Horizontal: 108°–30°
Vertical: 56°–17°
Diagonal: 131°–35°”
Iris Control Fixed
Close Focus Distance 0.8 m (2.62 ft)
DORI Distance
Lens Detect Observe Recognize Identify
W 44.1 m
(144.69 ft)
17.7 m
(58.07 ft)
8.8 m
(28.87 ft)
4.4 m
(14.44 ft)
T 144.8 m
(475.07 ft)
57.9 m
(189.96 ft)
29.0 m
(95.14 ft)
14.5 m
(47.57 ft)

Smart Event

Smart Event

IVS Tripwire; intrusion

Video

Video Compression H.265; H.264; H.264B; MJPEG (Only supported by the
sub stream)
Smart Codec Smart H.265+; Smart H.264+
Video Frame Rate
Main stream:
1920 × 1080@1–25/30 fps
Sub stream:
704 × 576@1–25 fps
704 × 480@1–30 fps
*The values above are the max. frame rates of each
stream; for multiple streams, the values will be subjected
to the total encoding capacity.
Stream Capability 2 streams
Resolution
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280
× 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF
(352 × 288/352 × 240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
White Balance Auto; natural; street lamp; outdoor; manual; regional
custom
Gain Control Auto; manual
Noise Reduction 3D NR

Motion Detection

Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Smart Illumination Yes
Image Rotation 0°/90°/180°/270° (Support 90°/270° with 1080p
resolution and lower)
Mirror Yes
Privacy Masking 4 areas

Alarm

Alarm Event
No SD card; SD card full; SD card error; network
disconnection; IP conflict; illegal access; motion
detection; video tampering; defocus detection; tripwire;
intrusion; voltage detection; security exception

Network

Network Port RJ-45 (10/100 Base-T)
SDK and API Yes
Cyber Security
Video encryption; firmware encryption; configuration
encryption; Digest; WSSE; account lockout; security logs;
IP/MAC filtering; generation and importing of X.509
certification; syslog; HTTPS; 802.1x; trusted boot; trusted
execution; trusted upgrade
Network Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP;
SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP;
Multicast; ICMP; IGMP; NFS; PPPoE; Boujour
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
User/Host 20 (Total bandwidth: 48 M)
Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser
IE
Chrome
Firefox
Management Software Smart PSS; DSS; DMSS
Mobile Client IOS; Android

Certification

Certification

Rev 001.001 © 2023 Dahua. All rights reserved. Design and specifications are subject to change without notice.
Pictures in the document are for reference only, and the actual product shall prevail.
Certifications
CE-LVD: EN 62368-1
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Power

Power Supply 12 V DC/PoE
Basic: 2 W (12 V DC); 2.7 W (PoE)
Power Consumption
Max. (ICR + H.265 + max. resolution + main stream + IR
intensity + WDR + IVS + vari-focal); 5.8 W (12 V DC); 6.4
W (PoE)

Environment

Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity ≤ 95%
Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Protection IP67; IK10

Structure

Casing Metal
Product Dimensions 88.9 mm × Φ122 mm (3.5″ × Φ4.8″)
Net Weight 0.45 kg (1.0 lb)
Gross Weight 0.63 kg (1.4 lb)
