System
Main Processor Embedded Processor
Operating System Embedded LINUX
Video and Audio
Analog Camera Input 8/16 Channel, BNC
HDCVI Camera 4K, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
AHD Camera 5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps
TVI Camera 5MP, 3MP, 1080P@25/30, 720P@25/30fps
CVBS Camera PAL/NTSC
IP Camera Input 8+4/16+8 Channel, each channel up to 8MP
Audio In/Out 1/1, RCA
Two-way Talk Reuse audio in/out, RCA
Recording
Compression H.264+/H.264
Resolution 4K, 5MP, 4MP, 3MP, 1080P, 720P, 960H, D1, CIF, QCIF
Record Rate
Main stream: 4K(1~7fps); 5MP(1~12fps); 4MP/3MP(1~15fps);
1080P/720P/960H/D1/CIF/QCIF (1~25/30fps)
Sub steram:960H(1~15fps);
D1/CIF/QCIF(1~25/30fps)
Bit Rate 1Kbps ~ 6144Kbps Per Channel
Record Mode
Manual, Schedule (Regular, Continuous), MD (Video
detection: Motion Detection, Video Loss, Tampering), Alarm,
Stop
Record Interval 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Postrecord: 10 ~ 300 sec
Display
Interface 1 HDMI, 1 VGA
Resolution
HDMI:3840×2160, 2560×1440, 1920×1080, 1280×1024,
1280×720, 1024×768
VGA: 1920×1080, 1280×1024, 1280×720, 1024×768
Multi-screen Display
When IP extension mode not enabled:
8CH: 1/4/8/9
16CH: 1/4/8/9/16
When IP extension mode enabled:
8CH: 1/4/8/9/16
16CH: 1/4/8/9/16/25
OSD Camera title, Time, Video loss, Camera lock, Motion
detection, Recording
Network
Interface 1 RJ-45 Port (1000M)
Network Function
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP,
DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server,P2P, IP Search
(Support Dahua IP camera, DVR, NVS, etc.)
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.42, CGI Conformant
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer
and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video
Loss,Tampering and Diagnosis
Alarm input N/A
Relay Output N/A
Playback and Backup
Playback 8CH: 1/4/9
16CH: 1/4/9/16
Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File,
Previous File, Next Camera, Previous Camera, Full Screen,
Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Storage
Internal HDD 2 SATA Ports, up to 8TB capacity for each disk
eSATA N/A
Auxiliary Interface
USB 2USB Ports (1 USB 2.0 , 1 USB 3.0)
RS232 N/A
RS485 1 Port, for PTZ Control
Electrical
Power Supply 8CH:DC12V/4A
16CH:DC12V/5A
Power Consumption <15W (Without HDD)
Construction
Dimensions 1U, 375mm×287mm×53mm (14.8″ x 11.3″ x 2.1″)
Net Weight 2.35kg (5.2 lb) (without HDD)
Gross Weight 3.2kg (7.05lb)
Installation Desktop installation
Environmental
Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH
Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH
Third-party Support
Third-party Support
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus,
Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo,
Sony, Videotec, Vivotek, and more
Certifications
Certifications
FCC: Part 15 Subpart B
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130,
EN 55024
UL: UL 60950-1
