Camera
Image Sensor 1/2.7″ CMOS
Effective Pixels 2560(H)×1440(V), 4MP
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25~1/100000s
NTSC: 1/30~1/100000s
Minimum Illumination 0.04Lux/F2.0, 30IRE, 0Lux IR on
S/N Ratio More than 65dB
IR Distance Up to 20m (66feet)
IR On/Off Control Auto / Manual
Lens
Lens Type Fixed lens / Fixed iris
Mount Type Board-in
Focal Length 3.6mm (6mm Optional)
Max Aperture F2.0
Angle of View H: 76.4° (48.6°)
V:41.6° (27.9°)
Focus Control N/A
Close Focus Distance 1400mm (2500mm)
55.12” (98.43”)
DORI Distance
Note: The DORI distance is a “general proximity” of distance which makes it easy to
pinpoint the right camera for your needs. The DORI distance is calculated based on
sensor specification and lab test result according to EN 62676-4 which defines the
criteria for Detect, Observe, Recognize and Identify respectively.
DORI
Definition Distance
Detect 25px/m
(8px/ft)
3.6mm: 80m(262ft)
6mm: 120m(394ft)
Observe 63px/m
(19px/ft)
3.6mm: 32m(105ft)
6mm: 48m(157ft)
Recognize 125px/m
(38px/ft)
3.6mm: 16m(52ft)
6mm: 24m(79ft)
Identify 250ppm
(76px/ft)
3.6mm: 8m(26ft)
6mm: 12m(39ft)
Pan / Tilt / Rotation
Pan/Tilt/Rotation
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotation: 0° ~ 360°
Video
Resolution 4MP (2560×1440)
Frame Rate 25/30fps@4MP,25/30fps@1080P
Video Output 1-channel BNC high definition video output / CVBS
video output (Can switch)
Day/Night Auto (ICR) / Manual
OSD Menu Multi-language
BLC Mode BLC / HLC / DWDR
WDR DWDR
Gain Control AGC
Noise Reduction 2D
White Balance Auto / Manual
Smart IR Auto / Manual
Certifications
Certifications CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
Interface
Audio Interface N/A
Eelectrical
Power Supply 12V DC ±30%
Power Consumption Max. 3.9W (12V DC, IR on)
Environmental
Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
* Start up should be done at above -40°C (-40°F)
Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
Ingress Protection & Vandal
Resistance IP67
Construction
Casing Plastic
Dimensions 70mm×70mm×149mm (2.76″×2.76″×5.87″)
Net Weight 0.15kg (0.33lb)
Gross Weight 0.19kg (0.42lb)
Ordering Information
Type Part Number Description
2MP Camera
DH-HAC-B1A41P 3.6mm
4MP HDCVI IR Bullet Camera, PAL
DH-HAC-B1A41P 6mm
DH-HAC-B1A41N 3.6mm 4MP HDCVI IR Bullet Camera,
NTSC DH-HAC-B1A41N 6mm
Accessories
PFA134 Junction box (For use alone or
with PFA152-E pole mount)
PFA152-E Pole mount (For use with PFA134
junction box)
PFM800-4K Passive Video Balun
PFM800B-4K Passive Video Balun
PFM321 12V 1A Power Adapter
PFM320D-015 12V 1.5A Power Adapter
PFM300 12V 2A Power Adapter
PFM820 UTC Controller
